The UNISTIM 5n is a premium electro therapy. It has four different channels for electrotherapy applications. In the development of the unit simplicity of operation and functionality were the principal consideration. All the available types of current and therapy are clearly displayed on a 5″ Colour touch screen. The intensity can be easily set with encoder. Pre-programmed memory with treatment applications offers protocols for more than 77 frequently occurring indications. And users can store their settings in user memory
- Both medium and low frequency currents
- Electro therapy-1 and Electro therapy-2 can be used simultaneously and individually
- Can treat 2 patients simultaneously
- 77 Pre-programs with condition wise protocols
- Cable and electrode checking mode
- Illustration image for Electrode placement
- User settable memory with patient name
- Encoder for intensity
- Light weight and compact design
- Easy to operate
- Plastic cabinet
- 5″ Colour Touch Display
- International standards and specifications
- Advanced patient safety system
- Independent intensity variation for each Channels
- 4 Channel for Electro Therapy
- Also designed for veterinary care
- Model : UNISTIM 5n
- Operation Mode : Electrical
- Usage : Clinical, Hospital, Personal
Interferential
- Carrier frequency – 2000Hz – 4000Hz(100Hzstep), 4000Hz – 10000Hz(500Hzstep)
- Base frequency – 1-250Hz(1Hzstep)
- Sweep frequency – 0-250Hz(1Hz step)
- Sweep modulation Programs – 1/1S ,5/1/5S ,6/6S
- Therapy Modes – Four pole Classic, Four pole Vector 90degree , Four pole Vector 45degree , Two pole pre-modulated
Russian current
- Frequency – 2000Hz – 4000Hz(100Hzstep), 4000Hz – 10000Hz(500Hzstep)
- Modulation – Constant/ Surge
- Ramp Rise/Fall – 1-10Sec(1Secstep)
- Burst – 30-250Hz(1Hzstep)
- Hold ON – 1-99Sec(1Secstep)
- Hold OFF – 1-99Sec(1Secstep)
Muscle stimulator currents
- Plain galvanic – Continuous DC current
- Int. galvanic – Diagnostic-0.01, 0.03, 0. 1, 0.3, 1, 3, 10, 30, 100, 300, 1000mSec Therapeutic -30-300mSec (10mSecs)
Diadynamic currents
- DIADYNAMIC CURRENTS – DF, MF, CP, LP, RS, MM
VMS(Vibratory Motor Stimulation)
- Frequency – 2-250Hz
- Waveform – Inverted Symmetric
- Pulse width – 20-400µs
Faradic
- Freq./p.width – 50hz/0.7 msec.
- Surge ontime – 1-10 sec.(in 1 sec step)
- Surge offtime – 1-10 sec.(in 1 sec step)
Tens
- Frequency – 2-250 Hz (in Hz variation)
- Pulse Width – 20-400 µsec(in 1µsec variation)
- Burst Frequency – 1-10Hz
- Sweep Frequency – 2-245Hz to 7-250Hz
- Waveform – Symmetric/Asymmetric/ Alternating/ Monophasic
- Modes – Continuous/ Burst/ Sweep burst & Sweep
Ultra reiz
- Frequency – 142.8Hz
- ONTime – 2 msec
- OFFTime – 5 msec
HV Pulse Current
- Frequency – 1-200Hz(1Hz step)
- Pulse width – 100µs
- Type – Constant/Surge
Micro Current
- Frequency – 1-1000Hz
- Intensity – 10µA-1000µA
Iontophoresis
- Dosage – 2-150mA/min (2mA/min step)
- Intensity – 1-5mA(0.5mAstep)
- Type – Constant/lnterrupted
SPOTCURE® TCR
SPOTCURE – TCR TECAR Therapy (Transfer of Energy Capacitive and Resistive) is a non-invasive treatment used in physiotherapy, sports medicine, and rehabilitation to promote healing, reduce pain, and improve mobility. It uses high frequency electromagnetic energy to stimulate deep tissues, enhancing blood circulation and cellular repair.
TECAR therapy involves two modes of energy transfer:
1. Capacitive Mode — Targets soft tissues like muscles and superficial structures.
2. Resistive Mode — Penetrates deeper into bones, tendons, and ligaments.
Applications
- Tendinitis, Low back pain
- Myalgia, Arthrosis, Bursitis
- Ligament injuries
- Ankle distortion
- Scar tissue
- Sport trauma
- Neuropathies
- Spine and peripheral joint disorders
Features
- Contact control sensor
- Plastic moulded light weight cabinet
- 5″ Touch TFT display
- Deep heat
- capacitive & resistive applicators
- 17 Condition wise Clinical Protocols
- 4 forms of sequential program
- 30 User memory
- Model : SPOTCURE TCR
- Operation Mode : Electrical
- Usage : Clinical, Hospital, Personal
- Output Frequency – 460kHz / 540kHz
- Output Power – 1-150W(1-10W/1Watts step), (10-150W/5 Watts step) at Resistive mode 1- 250VA (1-10VA/1VA step) (10-250VA/5 VA step) at capacitive mode
- Output Mode – Continuous / Pulsed
- Pulsed ON Time – 3 – 10 Sec (1 Sec Steps)
- Pulsed OFF Time – 1 – 10 Sec (1 Sec Step)
- Timer – 1 —99 min
- Sequential Treatment – Upto 4 forms of therapy
- Display – 5″ Touch TFT Display
- Mains Supply – 100-240V, 50/60 Hz
- Safety Class – Class l, Type BF (IEC 60601 -1)
- Dimensions – LxBxH-30x25x10.5cm
- Weight – 2.5kg
Digisonic-2s is an indigenous design with international standards and quality. It is an advanced trendsetter equipment from our R&D. The Digisonic-2s comes with 1 MHz and 3 MHz outputs with contact control sensor facility. Contact controls suspends the Ultrasound output when the transducer contact with the skin is insufficient. It has a microcontroller based circuitry with large LCD display for viewing all parameters. It is feature rich with Easily selectable Modes (1 Continuous and 9 pulse mode) and ultra feather touch keys for all functions.
HMS Medical Systems proudly presents UNISTIM® 5s an advanced interferential combination therapy equipment. It has more than six different types of electrotherapy applications such as Interferential, Russian, Tens, etc. All the available options such as types of current and types of therapy are clearly displayed on the large LCD screen. Five Soft Touch keys helps to set required parameters and settings. UNISTIM® 5s has pre-programmed settings with treatment applications offering protocols for more than 77 frequently occurring indications and therapies as well as custom settings to store in user memory.
- Both medium and low frequency Currents
- Russian stimulation
- 77 pre-programs and condition wise with protocols
- Cable and electrode Auto fault detection
- User settable memory
- Soft touch(capsense) keys
- Lightweight and compact design
- Easy to operate
- Plastic moulded cabinet
- Large graphic LCD display
- International standards and specifications
- Advanced patient safety system
- Output mode CC/CV
- Independent intensity controls for each channel
- Also designed for veterinary care
- Model : UNISTIM 5s
- Operation Mode : Electrical
- Usage : Clinical, Hospital, Personal
Interferential
- Carrier frequency – 2000hz/4000hz
- Base frequency – 1-150 hz (1hz step)
- Sweep frequency – 0-150 (1hz step)
- Sweep modulation program – 1/1s 1/5, 1/5s 6/6s
- Therapy Modes – Four pole interferential, Four pole vector 90°, Four pole vector 45°, Two pole pre-modulated
Russian current
- Frequency – 2500 hz
- Ramp rise/fall – 1-10 sec(1sec step)
- Burst – 50-250hz(10hz step)
- Hold on – 1-99 sec(1sec step)
- Hold off – 1-99 sec(1sec step)
Muscle stimulator currents
- Plain galvanic – Continuous DC Current
- Int.galvanic – Diagnostic – 0.01, 0.03, 0.1, 0.3, 1.3, 10, 30, 100, 300 msec(in 10 msec variation) Offtime – 500, 1000, 2000 msec.
Faradic
- Freq./p.width – 50hz/0.7 msec.
- Surge ontime – 1-10 sec.(in 1 sec.variation)
- Surge offtime – 1-6 sec.(in 1 sec.variation)
Tens
- Frequency – 2-250hz(in hz variation)
- Pulse width – 20-250 sec (In 1 sec variation )
- Burst Frequency – 1-10hz
Ultra reiz
- ONTime – 2 msec
- OFFTime – 5 msec
Low Frequency Alternating current
- Diadynamic currents – DF, MF, CP, LP, RS, MM
- TIMER – 0-60 MINUTES
- DISPLAY – 128X128 GRAPHIC BACKLITE LCD DISPLAY
- Mains voltage – 90-270v/50/60hz
- Safety class – Class 1, Type BF (IEC60601-1)
- DIMENSIONS – Lxbxh – 30x25x11.5 cms
- Weight – 3.2 kgs
The SONOMED 302 is a smart combination therapy. It has four different types of modality , including ultrasound and electrotherapy applications. In the development of the unit simplicity of operation and functionality were the principal consideration. All the available types of current and therapy are clearly displayed on a LCD screen. The corresponding parameters are easily set with soft touch keys and encoder. Pre-programmed memory with treatment applications offers protocols for more than 102 frequently occurring indications. And users can store their settings in user memory..
Sonotens an advanced solid state 1 MHz ultrasound therapy and dual channel TENS equipment is available in a sleek, compact and water-resistant design. It can be operated in either continuous mode or in pulsed mode. A digital display is provided to indicate all the necessary details like mode, power, timer etc. This combination therapy equipment come with an easily selectable micro-controller-based timer and plastic moulded lightweight transducer. Sonotens has six pre-programmed output modes which can be selected via a soft touch key and comes with a 15 mins built-in timer. It can be operated main power supply.
Features
Ultrasound
- Continuous and pulsed ultrasound
- Digital display of treatment time
- Provision for combination therapy
- Built in digital circuit and control all functions
- Digital display of applied intensity.
- Underwater treatment transducer
- Compact and light weight
- Non thermal effect
Tens
- Six pre programs
- Micro-controller controlled circuitry
- Built-in 15 min timer
- Separate intensity control for both channels.
- Model : SONOTENS
- Operation Mode : Electrical
- Usage : Clinical, Hospital, Personal
Technical Data
- Mains Voltage – 90 – 270V / 50 or 60 Hz
- Safety Class – Class I, Type BF (IEC 60601 -1)
- Dimensions – L x B x H – 21 x 22.5 x 6.5 cm
- Weight – 1.75 Kgs
INDOTRAC D is an advanced technology solid state circuitry based static / intermittent traction machine. We use Moulded Aluminium gear box and metal gears which gives longer life to our equipment. It has a silent, smooth and powerful motor to pull the appropriate weight. The treatment time, Rest time & Hold time is controlled by a microcontroller. Separate tension controls are provided for cervical and pelvic traction therapy.
Features
- Micro controller based
- Large LCD display
- Soft touch keys
- Imported sturdy & noise less motor
- Moulded aluminium gear box
- Patient safety remote
- Easy to operate
- Model : INDOTRAC D
- Operation Mode : Electrical
- Usage : Clinical, Hospital, Personal
Specifications
- Treatment Types – Continuous and Intermittent
- Traction force – 3 – 60 Kgs (120Kgs with Doubler)
- Hold Time – 10 – 80 sec (5sec step)
- Rest time – 1 – 20 sec (1sec step)
- Timer – 0 – 99 min. At the end of treatment time Acoustic signal and automatic reduction of traction force
Technical Data
- Mains Voltage – 220 V/ 50 Hz
- Safety Class – Class I, Type BF (IEC 60601 -1)
- Dimensions – L x B x H – 28 x 31 x 28 cms
- Weight – 11 Kgs
INDOTRAC2 is an advanced technology solid state circuitry Static / Intermittent traction unit. Moulded Aluminium gear box and metal gears gives long life to the equipment. It has silence smooth and powerful motor to pull the appropriate weight. The treatment time is controlled by digital timer and has indicators for Rest / Hold time. Separate tension control for cervical and pelvic.
Features
- mported Sturdy & noise less motor
- Moulded Aluminium Gear Box
- Patient safety remote
- Easy to operate
- Model : INDOTRAC2
- Operation Mode : Electrical
- Usage : Clinical, Hospital, Personal
Specifications
- Therapy types – Continuous and intermittent
- Traction force – 3 – 60 Kgs (120 Kg with doubler)
- Hold time – 20, 40, 60, 80 seconds
- Rest time – 1, 5, 10, 20 seconds
- Timer – 0 – 99 min.At the end of treatment time Acoustic signal and automatic reduction of traction force
Technical Data
- Mains Voltage – 220V / 50 Hz
- Safety class – Class I, Type BF (IEC 60601-1)
- Dimensions – L x B x H – 28 x 31 x 28 cms
- Weight – 11 Kgs
DIGITRAC 101 is advanced Cervical/Lumber traction unit from HMS R & D. During the development, we take care of Patient safety and Durability of the device. DIGITRAC 101 is fully microcontroller controller device, it has large LCD display for parameters and easy to operate.
Features
- Progressive and step increment
- Variable speed selections
- High force range upto 90 Kgs
- Low force range upto 85 Kgs
- Wide input voltage range
- User defined Hold, Rest and Treatment time
- Graphic LCD display for all parameters
- User-friendly digital interface
- Provision for Saunders fitting
- Reliable, durable heavy-duty motor
- Noiseless operation
- Easy to mount in table
- Light weight
- Model : DIGITRAC 101
- Operation Mode : Electrical
- Usage : Clinical, Hospital, Personal
Specification
- Traction force – 3 Kg to 90 Kg (1 Kg step)
- Base force – 2 Kg to 85 Kg (1 Kg step)
- Traction mode – Cervical and Lumber
- Treatment time – 01 to 99 min (1 min step)
- Hold time – 01 to 99 sec (1 sec step)
- Rest time – 01 to 99 min (1 sec step)
- Traction speed – 5 speed
- Progressive step – 1 to 10 step (max)
Technical Data
- Input Voltage – 100 to 240 V AC 50/60 Hz
- Electrical class – Class 1 Type B
- Power consumption – 50 Watts
- Dimensions – LXBXW – 285mmx198mmx324mm
- Weight – 9.5 Kgs
SONOMED 7s Interferential and Ultrasound Therapy machine is a high quality, advanced, Inferential & Ultrasound combination Therapy equipment. Our equipment is a combination of interferential, Russian, TENS, Muscle Stimulator and Ultrasound Therapy machine. It is designed in such a way that it can be used to provide IFT and USD separately or in a combined manner. It is quite effective in sports medicine and It meets all International Standards and Specifications.
